| Model: |
EM-5 |
| Color: |
Black/Grey/Dark green |
| Size: |
14″/16″/18″ |
| Frame: |
CYCTRAC-EM5, Alu alloy AL7005,Flat weld&Smooth,Inner cables, Thru-
axle12*148 Boost, UDH tail hook |
| Fork: |
RS, MgAl alloy,Air, Remote,Thru-axle 15*110 |
| Handlebar: |
RS, Alu alloy,Matte,Handlebar 31.8 ×720 |
| Seatpost: |
Stem 80mm,Seat post 31.6 ×350mm,Clamps 34.9mm QR |
| Derailleur: |
SHIMANO DEORE/M6100-12S |
| Shifters: |
SHIMANO DEORE/M6100-12S |
| FD: |
None |
| RD: |
SHIMANO DEORE/M6100-12S |
| Crankset: |
Matching with Mid Motor, 38T |
| Cassette: |
SUNSHINE-12S, 11-50T |
| Chain: |
SUMC-12s |
| Brake: |
SHIMANO MT200 hydraulic disc brake, 180/ 180mm |
| tor System: |
Bafang Mid, M510, 36V250W (48V250W) |
Bafang Mid, M560, 48V500W |
| Battery: |
amsung 21700 Li-ion,720Wh,36V20A(48V15 |
| ASamsung 21700 Li-ion, 720Wh, 48V15A |
|
| HMI: |
Bafang-C030, LCD digital (Built in Top tube) |
afang-C030, LCD digital (Built in Top tub |
| Wheels: |
RS, Alu alloy with Double-wall&Rivets, W25× H21mm |
| HubA: |
lu alloy,4-sealed Bearings,Slotted,32Holes,Thru-axle F15× 110_R12× 148mm Boos |
| Rim: |
RS, Alu alloy with Double-wall&Rivets, W25× H21mm |
| Tire: |
MAXXIS, 29/27.5 ×2.25″ |
| Grips: |
Circular 22.2 × 120mm, PU leather&locking Ring |
|
| Config: |
Bafang Mid, M510, 36V250W (48V250W |
) Bafang Mid, M560, 48V500W |
| Bike weight: |
22.3kg |
22.7kg |
|
|
|
|
|
|
|
|
|
