| Bike Model |
KOZO2（UTDI2 Version） |
| ConfRev |
Shimano Ultegra Di2 ST-R8170 24Speed Standard version |
Shimano Ultegra Di2 ST-R8170 24S Competition version |
| Wheel Size |
700C |
| Frame Height |
46cm 49cm 52cm 55cm |
| Bike Color |
Matte Black/Yellow/White/Gray/Other MetallicRed/Green/Blue/Purple/Holographic Explosive Blue/Purple |
| Net Weight |
8.2 kg |
7.7 kg |
| Frame set |
Frame: |
KOZO2 Toray T800 EPS High Modulus Carbon Endurance Frame, Full Internal Routing, 12x142mm Thru-Axle Disc Brake |
| Handlebar |
Handlebar: |
KOZO2 Toray T800 High modulus Carbon fiber, Integrated Handlebar&Stem(400*100mm), full Inner-Cables |
|
Seatpost: |
KOZO2350mm uncut Toray T800 EPS high-modulus carbon fiber seatpost |
|
Clamp: |
KOZO2 Frame-matched / integrated clamp with protective rubber sleeve |
| Fork |
Fork: |
KOZO2 (Disc brake, 12×100 thru-axle) Toray T800 EPS high-modulus carbon fiber road rigid fork |
|
Head Sets: |
Alu alloy CNC with sealed-Bearings 52*52mm |
|
Washer: |
Dedicated for Inner-Cables |
| WHEELSET |
Hub: |
SHOXSOUL Ultra-light Aluminum / 54T Ratchet / 4-Bearing Cassette Hub / 24H Front & 24H Rear / Centerlock / Disc Thru-Axle F12×100 – R12×142 |
SHOXSOUL Ultra-light carbon fiber hub/ 54T Ratchet / 4-Bearing Cassette Hub / 24H Front & 24H Rear / Centerlock / Disc Thru-Axle F12×100 – R12×142 |
|
Wheel: |
SHOXSOUL carbon fiber / flat-profile rim / 88mm rim height / clincher |
SHOXSOUL Ultralight carbon wheels / flat-profile rim / 60mm rim height / clincher (1180g) |
|
Spoke: |
High-rigidity flat spoke, 14G |
carbon fiber flat spoke, 14G |
|
Tyre: |
GOODYEAR EAGLE SPORT, lightweight folding, 700×28C, black |
GOODYEAR EAGLE SPORT, lightweight folding, 700×28C, black |
|
Inner tube |
Kozo inner tube |
TPU inner tube |
|
Saddle： |
Comfortable&lightweight for racing |
Carbon Fiber Saddle 120g |
|
Belt： |
PU breathable, comfortable, anti-slip |
Titanium alloy screws: breathable, comfortable, and non-slip. |
| Brake |
Brake: |
Shimano Ultegra BR-R8170 Flat Mount Hydraulic Disc Brake Calipers |
|
Disc: |
160/160mm IIIpro high quality disc |
| Derailleur |
Shifter: |
Shimano Ultegra Di2 ST-R8170 Hydraulic Disc Brake Shifters (2×12-Speed |
|
F-D: |
Shimano Ultegra Di2 FD-R8150 Front Derailleur (2-Speed) |
|
R-D: |
Shimano Ultegra Di2 RD-R8150 Rear Derailleur (12-Speed) |
|
Cranksets: |
Shimano Ultegra FC-R8100 Aluminum HollowTech Crankset, 34-50T |
|
Cassettes: |
Shimano Ultegra CS-R8101 12-Speed Cassette, 11-34T |
|
Chain: |
Shimano Deore XT CN-M8100 12-Speed Chain |
|
BB: |
SENICX T47 Threaded 24mm Spindle, HollowTech Bearings |
|
Cables： |
JAGWIRE |
|
| Unit Price, USD, EXW (Level-1 (1 bike) /Level-2 (sample price)/ Level-3 （5-19pcs)/ Level-4 (20-50pcs) |
| LEVEL-1 |
2199 |
2499 |
| LEVEL-2 |
2099 |
2399 |
| LEVEL-3 |
2020 |
2299 |
| LEVEL-4 |
1920 |
2199 |
